One More KE7 Manual

So just this past weekend I ran across another KE-7 manual, this one with a bunch of plates and a great full cutaway diagram. Figured I’d put that one up on the site now, since it does a much better job showing the internals than last week’s pieces.

KE7 Manual (German)

KE-7 LMG cutaway

We’ve got some cool stuff coming up this week – I have some more video material that I just need to edit together…I think you’ll enjoy it.


  1. i think this manual about this experimetal automatic rifle is great but sadly the scans of the plates are not complete, could you scan the schematics diagrams again please…
    best regards
    percy olivas
