Eriksen Machine Gun

Sometimes, there is just no good reason to build a gun design, and the Eriksen machine gun is a good example. A sample of the Eriksen machine gun was sent to the CISA (Chief Inspector of Small Arms) in 1927 for evaluation, and got no farther.

Eriksen machine gun, open to show internals

Eriksen machine gun, open to show internals

Part of the problem was that the gun was sent without any ammunition, which makes it somewhat difficult to test (it used a 6.5mm cartridge). But beyond that, it was a design which was different, but offered no apparent improvement over the machine guns already in service with the US military (which at the time were primarily Brownings, the 1919, 1917, and BAR). Its feed mechanism was similar to the Japanese Type 11, as it had a feed box which held 10 stripper clips of 5 rounds each. A spring mechanism would push the clips up, and the top one would feed into the left side of the gun. This sounds like a good idea to simplify logistics and have a units machine guns use the same ammunition as the riflemen, but it tends to be unreliable in use, because the mechanism is complex and easily stopped by dirt. The Russians also experimented with this type of feed with the Kubynov machine gun (a modification of the DP).

The Eriksen action used a round block pivoting around an offset pin powered by a gas piston to lock the breech. This is similar in theory to the Maxim toggle lock – as long as the pivot pin (9), rod connecting to the bolt face (10)  and the firing chamber are on a line the breech will remain locked. Once the gas piston and its connecting rod (7) move rearwards, the line is broken and the breech can open easily.

Eriksen machine gun operating mechanism

Eriksen machine gun operating mechanism

You can download the 1925 patent filed by Johan Eriksen for this design here:

US Patent #1,497,096 (J. Eriksen, “Machine Gun”, January 24, 1924)

A couple pages from the CISA minutes are also available describing the actual Eriksen gun sent to the US for evaluation, both here and on the Eriksen machine gun page in the Vault:

CISA Description of the Eriksen Machine Gun (English, 1927)

CISA Description of the Eriksen Machine Gun (English, 1927)
